Description
Features
- Bolt-on fitment compatible with Toyota Tacoma 2016-2021.
- Allows you to mount two Stage Series LED Pods above the hood.
- Utilizes existing mounting points and hardware for a simple installation.
- Thick-gauge stainless steel construction.
- Low-profile design.
Overview
Perfect fitment. The Stage Series Backlit Ditch Light Kit compatible with the Toyota Tacoma 2016-2021 allows you to easily mount two SS3 or SSC2 Backlit Pods above the hood. These application-specific brackets were CAD-designed to install using factory mounting points. No cutting or drilling required! This kit features a low profile design while minimizing glare and will not interfere with raising or lowering the hood.
Backlight Functionality. Both the SS3 and SSC2 pods included in our Stage Series Ditch Light Kits feature a brilliant Amber backlight. This integrated backlight gives you an additional accent light along with the main beam. The backlight fully illuminates the TIR optic providing a more unique and modern look than the small indicator LEDs found in other products. To power the backlight use the included harness to tap your desired vehicle function.
Built to last. The brackets in this kit are constructed out of thick-gauge stainless steel. Unlike other options made out of mild steel these brackets are full stainless steel and won’t corrode over time. With their thick-gauge construction you also won’t experience any vibration or bouncing while driving.
Focused. Optics like reflectors or simple lenses lose light internally and to glare. However the custom-engineered TIR optic in the SS3 and SSC2 collects all of the light from the LED and directs it only where you need it drastically reducing glare and improving total efficiency.
Included in the box:
- Two (2) SS3 or SSC2 Standard LED Pods
- Two (2) Ditch light brackets
- Two (2) SS3 or SSC2 Mounting brackets
- One (1) Heavy Duty Dual Output 4-pin Wiring Harness
- Mounting hardware
- Mounting guide
Resources
Installation Instructions
Specifications:
| beam_angle | Combo (Driving and Flood) |
| brand_logo | https://www.asapnetwork.org/sites/default/files/brands/icons/diode%20ASAP.png |
| Connector | Deutsch DT Input |
| height | 12.0 |
| last_update | 2022-11-15 19:02:18 |
| last_update | 2023-06-21 16:49:58 |
| length | 15.0 |
| lens_color | Yellow |
| light_pattern | Sport |
| lumens | 1 300 Lumens |
| LUX | 28 100 cd |
| material_l | Polycarbonate |
| material_l | Polycarbonate Lens, Aluminum Casting, Rubber Gasket |
| part_number_type | Offroad |
| Series | SS3 Series |
| sold_as | Pair |
| Universal | No |
| vehicle_type | Truck/SUV |
| volts | 9-16V |
| Warranty | 8 year warranty |
| waterproof_rating | IP69K Waterproof High Pressure |
| weight | 5.69 |
| width | 9.0 |
